Welded Stainless Steel Pipes/Tubes

Welded CS Pipe

Standard: ASTM A53, A252, DIN1626, API 5L, API5CT
Steel Grade: Gr. A, Gr. B, X42, X52, X56, X60, X65, X70, St37, St52
Out Diameter: ERW(1/2”~24”), LSAW(16”~64”), SSAW(8”~100”)
Wall Thickness: 2-20MM
Product description：welded carbon steel pipe/tube,produced under the norm of ASTM A53, API 5L,grade B,X42, X52, X56, X60, X65, X70
INQUIRY

Application:

Carbon steel welded pipe and tube are used in low & high-pressure conditions. They are highly resistant to shock and vibration making it ideal to transport fluids. Carbon steel pipes are widely used in a number of industries, such as transporting water and sewage, oil and gas industries, boiler and condenser tubes, high-pressure applications, and chemical processing.

- Transporting water and sewage
- Oil and gas industries
- Boiler and condenser tubes
- High-pressure applications
- Chemical processing

Specification :

ASTM / ASME
Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Electric-Resistance-Welded Steel Pipes	ASTM A135	42.2~114.3 x 2.11~2.63	A
Pipes for Piling Usage	ASTM A252	219.1~508 x 3.6~12.7	Gr2, Gr3
Tubes for General Structural Purpose	ASTM A500	21.3~273 x 2.11~12.7	Carbon Stee
Square Pipes for General Structural Purpose	ASTM A500	25 x 25~160 x 160 x 1.2~8.0	Carbon Steel

API SPEC 5L
Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Line Pipes	API 5L	60.3~273.1 x 2.77~12.7	A25, A, B, X42, X46, X52, X56, X60, X65

API SPEC 5CT
Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Casting	API 5CT	48.3~273 x 2.77~11.43	J55, K55, N80, L80
Tubing	API 5CT	48.3~273 x 2.77~11.43	J55, K55, N80, L80, H40

DIN
Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Threaded Steel Pipes	DIN 2440	21~164 x 2.65~4.85	Carbon Steel

EN
Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Scaffolding Pipes	EN 39	48.3 x 3.2~4	Carbon Steel

BS
Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Screwed and Socketed Steel Tubes	BS 1387	21.4~113.9 x 2~3.6	Carbon Steel
